GNSS PRODUCTS

X5 Stick
Pocket-sized GNSS precision device

The X5 Stick is a high-precision, portable, lightweight GNSS receiver compatible with Android and iOS. It’s ideal for field work requiring centimeter-level accuracy in seconds.

PROFESSIONAL USES

Power, precision and reliability in a single device

Topography

Construction

Agriculture

Cartography / GIS

Roads

FEATURES

Main Features
x5 stick campo 2x5 stick campo 2
High-precision mobile surveying
Performs GNSS data collection with centimeter-level accuracy; includes point tagging and immediate cloud synchronization to prevent data loss.
X5 Stick campoX5 Stick campo
Cloud project management
Create, organize, and automatically synchronize projects with MettaGO 360.
X5 Stick 3X5 Stick 3
Advanced visualization
Integrated maps (standard, satellite, topographic) and drawing of lines and polygons within the app.

TECHNICAL SPECIFICATIONS

Compact and ergonomic design

CHANNELS

184

FIRST FIX TIME

20 s (cold), 2 s (hot)

FREQUENCY

1 Hz TO 5 Hz

COMPATIBLE FORMATS

  • RTCM3.X (input)
  • NMEA (output)
  • Raw data in RINEX format (for PPK and PPP-Static)

COMPATIBLE CONSTELLATIONS

  • GPS (L1C/A, L2C)
  • GLONASS (L1OF, L2OF)
  • Galileo (E1B/C, E5b)
  • Beidou (B1I, B2I)
X5 STICK
The exterior
Dimensions: 360 mm x 32 mm
Operating temperature: -20 °C to 65 °C
Battery: 5000 mAh
Maximum power consumption: 500 mA
Weight: 275 g

INCLUDED FREE:

MettaGO
Enhance your GNSS receiver

The professional app for smart surveying and layout.
MettaGO is the mobile app designed for professionals who need efficiency, control, and centimeter-level accuracy in the field.

COMPLEMENTARY TECHNOLOGY

Complete your precision tool kit

All-in-one GNSS RTK: Laser, dual camera, 120° IMU and 4G.

Original price was: $ 8,799.00.Current price is: $ 7,799.00.

X5 Stick + MettaGO 360 + GEODNET RTK (1 an de licence)

Original price was: $ 1,799.00.Current price is: $ 1,699.00.

X5 Stick + MettaGO 360 + GEODNET RTK (1 year license)

Original price was: $ 1,999.00.Current price is: $ 1,899.00.

Inertial Measurement Unit (IMU)

$ 1,999.00

Select options This product has multiple variants. The options may be chosen on the product page

High-precision GNSS receiver

$ 1,799.00

Select options This product has multiple variants. The options may be chosen on the product page

High-precision GNSS receiver

$ 721.00

Select options This product has multiple variants. The options may be chosen on the product page

High-precision GNSS receiver

$ 880.00

High-precision GNSS receiver

$ 6,900.00

Marketed by TKI (Germany)

Ready to take precision to the next level?

The GNSS technology you need, with the support you deserve.
